Vulnerability Research

Corrupting the Hive Mind: Persistence Through Forgotten Windows Internals

Eventually after you write a tool, the time comes to make it public. That time has come for Swarmer, a tool for stealthy modification of the Windows Registry as a low privilege user. It’s been almost a year since we first deployed this technique in the wild, and given enough time has passed, it seems appropriate to share what we’ve learned about one of Windows’ dustier corners regarding mandatory user profiles.

The Problem with Registry Persistence

If you’ve spent any time on a red team engagement in the last decade, you’ve probably noticed that the classic registry run key persistence trick has gotten noisy. Endpoint Detection and Response (EDR) solutions have gotten quite good at watching for RegSetValue calls that touch the usual suspects under HKCU\SOFTWARE\Microsoft\Windows\CurrentVersion\Run. Write a key there and you might as well send the blue team a calendar invite to burn your shell.

The fundamental issue is that EDR hooks into the standard Registry APIs. Every RegCreateKey, RegSetValue, and similar APIs are logged, analyzed, and potentially flagged. This creates an interesting challenge: how do you get registry persistence without actually touching the registry?

Enter the Mandatory User Profile

Windows is absolutely riddled with legacy cruft. Features built for Windows NT that somehow survived into Windows 11, backwards compatibility shims that nobody remembers, and configuration mechanisms that predate most security tooling. Mandatory User Profiles fall squarely into this category.

The concept is straightforward: in enterprise environments, administrators sometimes want to enforce a specific user profile that resets on each login. To accomplish this, Windows supports a file called NTUSER.MAN (the .MAN standing for “mandatory”) which takes precedence over the usual NTUSER.DAT registry hive stored in %USERPROFILE% when a user logs in.

While this is expected to be an administrator capability, there’s actually nothing stopping users from taking a valid NTUSER.DAT, copying it, and renaming it to NTUSER.MAN in the %USERPROFILE% folder thereby triggering the same mandatory hive override at boot time.

But we don’t want to just copy an existing hive, we want to modify it. Unfortunately for us, NTUSER.DAT cannot be edited while the user is logged in because it’s loaded into memory. The only way to propagate a change here is to modify the registry using regedit using those same standard registry APIs we want to avoid. Even with a copy of the file, the registry hive format is still technically undocumented and making changes to it without using the registry APIs is not recommended.

The Offline Registry API Rabbit Hole

So we have a mechanism to overwrite an existing hive, but how do you modify a valid binary registry hive without using the standard registry APIs that EDR monitors?

The answer, predictably, is another piece of legacy Windows infrastructure: the Offline Registry Library (Offreg.dll). This library was designed for scenarios like Windows setup, backup tools, and forensic analysis—situations where you need to manipulate a registry hive file without actually loading it into the running system.

Microsoft’s documentation includes a delightful warning:

Applications should not use the offline registry functions to bypass the security requirements of the system registry.

Obviously we’re not going to listen to that.

The Offline Registry API provides everything we need: ORCreateHive, OROpenHive, ORCreateKey, ORSetValue, and ORSaveHive. Using these functions, we can construct a complete registry hive without making a single standard registry API call. Process Monitor sees nothing. ETW sees nothing. The EDR sees nothing interesting.

As an added bonus, we don’t even need to use these APIs on our target host, we just need to export the hive into a format we can parse on any Windows machine. We can just run reg export against HKCU and take the text output of that. Alternatively, if we want to avoid any shell commands at all, we can run any BOF that can dump registry keys like TrustedSec’s reg_query BOF.

Building Swarmer

The result of this research is Swarmer, a tool we’ve been using internally since February 2025. The workflow is straightforward:

Export the target user’s HKCU registry (via reg export or our BOF-based approach)
Make whatever modifications you want to the exported data
Use Swarmer to convert the modified export into a binary hive
Drop the resulting NTUSER.MAN file into the user’s profile directory

swarmer.exe exported.reg NTUSER.MAN

Or, if you want to add a startup entry in one shot:

swarmer.exe --startup-key "Updater" --startup-value "C:\Path\To\payload.exe" exported.reg NTUSER.MAN

The tool also supports parsing the output of TrustedSec’s reg_query BOF directly, which is useful when you’re working from a C2 implant and don’t want to touch disk with a .reg file:

swarmer.exe --bof --startup-key "Updater" --startup-value "C:\Path\To\payload.exe" bof_output.txt NTUSER.MAN

Implementation Notes

The actual implementation was more annoying than expected. ORCreateHive doesn’t produce a file that Windows will accept as a valid NTUSER.MAN—something about the internal structure differs from what the system expects. The workaround involves using RegLoadAppKeyW to create an initial empty hive file (this is a legitimate API that doesn’t require admin), then opening that file with OROpenHive and populating it from there.

We built Swarmer in C# for a few reasons: easy interop with the Windows APIs via P/Invoke, straightforward deployment as either an executable or a PowerShell module, and the ability to run it entirely offline on an operator machine if you’re feeling paranoid about even the Offline Registry API being logged on the target.

Import-Module '.\swarmer.dll'
Convert-RegToHive -InputPath '.\exported.reg' -OutputPath '.\NTUSER.MAN'

The Caveats

This technique isn’t without its limitations—no persistence mechanism is perfect.

One-shot deal: Once NTUSER.MAN exists, the user’s profile becomes mandatory. Any changes the user makes during their session won’t persist across logins. More importantly for our purposes, you can’t update the persistence without admin privileges to delete the NTUSER.MAN file. Get it right the first time.

User must log out and back in: The hive is only loaded at login time. If you’re looking for immediate persistence, this isn’t it. On the flip side, this means the persistence survives reboots without any additional work.

HKCU only: This technique affects the user’s registry hive, not HKLM. You’re limited to per-user persistence mechanisms.

There are edge cases: You can corrupt the registry so that the user cannot log in anymore. It does happen – this tool does not handle EVERY edge case in registry configuration. We recommend testing any hives on a machine you control before deploying them. But this will work for most Windows registry configurations, even in large enterprise environments.

Detection opportunities still exist: While we avoid the standard registry APIs, there are still artifacts. A file suddenly appearing in the user profile directory might trigger alerts. The Offreg.dll library being loaded by an unexpected process could be flagged by behavioral analysis. And of course, once the persistence fires at login, whatever you’re executing becomes visible. This can be mitigated by taking the BOF approach and then modifying the hive on a machine you control, but NTUSER.MAN writes are hard to hide.

Why Share This Now?

We’ve been using this technique operationally since February 2025. It’s proven reliable across Windows 10 and 11 systems, and we’ve had good success avoiding detection during engagements. Given that the underlying Windows behavior is publicly documented (if somewhat obscure), it seems fair to give defenders visibility into the technique.

The fundamental lesson here isn’t specific to mandatory user profiles—it’s that Windows contains decades of accumulated complexity, and much of it predates modern security tooling. Features designed for legitimate administrative purposes can often be repurposed for offensive use. The Offline Registry API exists for good reasons, but those good reasons don’t prevent abuse.

For defenders: consider monitoring for NTUSER.MAN file creation in user profile directories, especially when it doesn’t come from an enterprise profile management system. The loading of Offreg.dll by processes that don’t typically need offline registry access might also be worth investigating.

For attackers: there’s always another forgotten corner of Windows waiting to be explored.
